Alpine MDA-W700J
| Name | MDA-W700J |
|---|---|
| Manufacturer | Alpine |
| Released | 1999/10 |
| Device type | auto |
| Recorder | Player |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes - 76-90Mhz |
| Dimensions | 2-Din W 178 × H 100 × D 155 mm |
| Weight | 2.5kg |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | |
| Voltage | 12 |
| Power cable | |
| Price (launch) | |
| ¥79 800 | |
| - | |
| Inputs | CD |
| Outputs | Speaker amplifier |
| Control |
Alpine MDA-W700J. Seems to be a color variant of the MDA-W700JB. Should share the new CD pickup and MD mechanism with the MDA-W779JB.
MD/CD player with:
- MD/CD kanji title display
- T-DHE (Theatre Sound DHE)
- DSP
- 7 Band EQ (…63Hz/160Hz/400Hz/1kHz/2.5kHz/6.3kHz/16kHz（each± 10dB）)
- Equipped with “Glide Wing”, an advanced and smart display action
- DHE (Digital Harmonics Enhancer) - uses a unique digital technology to revive the harmonics (overtones) that are lost when recording onto an MD, realizing music playback that is closer to the original sound
Technical Specs:
- MD S/N: 105dB. Dynamic Range: 90dB.
- CD S/N: 105dB. Dynamic Range: 93dB. Channel Separation: 86dB.
- 44W × 4ch amplifier
Content adapted from: Alpine announcement/press release [*] Alpine announcement/press release (MiniDisc Wiki mirror) [*] Alpine MDA-W700J Manual Page [*]
Manuals
Alpine MDA-W700J Owners Manual JP
Alpine MDA-W700JB Installation Manual
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
