Tascam MD-CD1BMK2
| Name | MD-CD1BMK2 |
|---|---|
| Manufacturer | Tascam |
| Released | 2010/07 |
| Device type | pro |
| Recorder | Recorder |
| MDLP | Yes |
| NetMD | No |
| Hi-MD | No |
| Radio | No |
| Dimensions | 483 (width) x 94 (height) x 308 (depth) mm |
| Weight | 5.8kg |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | |
| Voltage | 100 |
| Power cable | |
| Price (launch) | |
| ¥124 200 | |
| - | |
| Inputs | RCA in, XLR in, Digital optical (TOSLINK) |
| Outputs | 1/4 inch headphone, RCA out, XLR out, Digital optical (TOSLINK) |
| Control | PS/2 keyboard, RS-232 serial |
Tascam MD-CD1BMK2 / MD-CD1BMKII.
Supports CD/CD-R/CD-RW/CD-ROM (MP3) discs CD-TEXT display (when stopped: disc title, during playback: track title) ID3 tag display when playing MP3 files (song title only)
CD:
- -50 to +16% pitch control playback (*)
- (variable steps can be set in the range of 0.1 to 1.0% in increments of 0.1, CD-DA discs only)
- ±6 semitone key control playback (semitone steps, CD-DA disc only) (*)
MD:
- ±12.5% pitch control playback (variable steps can be set in 0.1 to 1.0% range) (*)
Changes from MD-CD1B:
- Expanded CD pitch control range. (+16.0 to -50.0%) (*)
- Added Time Track Increment to MD Auto Track.
- IR REMOTE Enable/Disable function.
- Set whether to stop or skip to the next file when Decode Err occurs during MP3 playback.
- Select MD/CD display with RS-232C.
- Perform track skip during display selection with MULTI JOG.
- Improved CD Auto cue accuracy.
- Factory reset function / RoHS compliant
Release date is estimated based on catalog
Content adapted from: Tascam Product Page [*]
Manuals
TASCAM md-cd1mkii Owners Manual JP (2 page pro supplement)
rs-232c protocol v.101
Tascam MD-CD1BMKii Specs
DXF Drawings
Tascam 07-2010 catalog
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email..
