Sony MJ-L1
| Name | MJ-L1 |
|---|---|
| Manufacturer | Sony |
| Released | 1996/01 |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 430 x 95 x 290mm Main Unit |
| Weight | 7kg |
| ATRAC ver | 3 |
| Battery | |
| Battery notes | |
| Sidecar (depr) | No |
| Voltage | 100 |
| Power cable | |
| Price (launch) | |
| ¥150 000 | |
| - | |
| Inputs | RCA in, CD, Radio recording |
| Outputs | RCA out, Speaker amplifier |
| Control |
Main body part# HCD-MJ1.
“Flat” design. Can record from CD, Radio, or RCA inputs (Note that the only digital recording from this device is through CDs). CD copies include disc memo information, and radio recordings will use the station name. Can use the RM-D10P title remote, but comes with the RM-SMJ1 remote.
MD Mechanism: MDM-2ER
Base Unit: MBU-2
Optical Pick-Up: KMS-210A
ATRAC IC: CXD2535BR
Manuals
Sony MJ-L1 User Manual
Sony HCD-MJ1 Service Manual
Sony HCD-MJ1A Service Manual (only the differences from HCD-MJ1)
