Sharp MD-X60
| Name | MD-X60 |
|---|---|
| Manufacturer | Sharp |
| Released | 1998/03 |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes - 88-108MHz |
| Dimensions | 240 (width) x 332 (height) x 325 (depth) mm |
| Weight | 8600 |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | No |
| Voltage | 120, 230 |
| Power cable | AC |
| Price (launch) | |
| ¥76 000 | |
| - | |
| Inputs | 3.5mm line in (analog-only), RCA in, Digital optical (TOSLINK), Tape deck |
| Outputs | 3.5mm headphone, RCA out, Speaker amplifier, Tape deck |
| Control |
MD-X60 (North America/Mexico), MD-X60H (Europe/Asia/Middle East)
- CD→MD 2) MD→MD 3) TAPE→MD 4) CD→TAPE 5) MD→TAPE 5 types of “one-shot edit buttons” for easy editing between MD, CD, and cassette
- Simultaneous editing of sound and text from MD to MD (using our portable MD and optional connection cable)
- “Digital input terminal” that can record Internet distribution music to MD (connected to optional sound card)
- Equipped with a “sampling rate converter” that supports digital recording of expanding CS/BS music broadcasts
- “Large 4-color FL display” with spectrum analyzer that is fun to look at
Optical Pickup: RCTRH8173AFZZ
ATRAC IC: LR376481
Content adapted from: Sharp Press Release [*] Sharp Press Release (MiniDisc Wiki mirror) [*] Sharp Product Page [*] Sharp Product Page (MiniDisc Wiki mirror) [*] Sharp Specs Page [*] Sharp Specs Page (MiniDisc Wiki mirror) [*]
Manuals
Sharp MD-X60 User Manual
Sharp MD-X60 Service Manual
Repair
Photos
