Kenwood M929
| Name | M929 |
|---|---|
| Manufacturer | Kenwood |
| Released | 2001/02 |
| Device type | auto |
| Recorder | Player |
| MDLP | Yes |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 1-Din 178 x 50 x 160mm |
| Weight | 1700 |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | |
| Voltage | 12 |
| Power cable | |
| Price (launch) | |
| ¥63 000 | |
| - | |
| Inputs | |
| Outputs | |
| Control |
Kenwood M929.
[MD part]
- Frequency characteristics: 20Hz to 20kHz (± 1dB)
- S / N ratio: 90dB (1kHz)
- Dynamic range: 90dB
- Stereo separation: 85dB
[FM section]
- Reception frequency range: 76.0MHz-90.0MHz (100kHz step)
[AM department]
- Reception frequency range: 522kHz to 1629kHz (9kHz step)
- Sensitivity: 28 dBμ
[EQ section]
- Equalizer center frequency: 60,120,250,500,1k,2k, 4k, 8k, 16kHz
- Variable range: ± 12 dB
[Audio section]
- Maximum output: 45W x 4
- Rated output: 28W x 4 (4Ω, 1kHz, 10% THD)
- Pre-out level: 1500mV (FM / 10kΩ)
[Common part]
- Power supply voltage: 14.4V (11-16V)
- Maximum current consumption: 10A
- Embedded dimensions: 178 (W) x 50 (H) x 160 (D) mm
- Mass: 1.7 kg
Content adapted from: Kenwood Press Release (archived) [*] Kenwood Press Release (archived) (MiniDisc Wiki mirror) [*] Kenwood Product Page [*] Kenwood Product Page (MiniDisc Wiki mirror) [*] Kenwood Product Page 2 [*] Kenwood Product Page 2 (MiniDisc Wiki mirror) [*] av.watch [*] response.jp [*]
