Kenwood DPX-6000MD
| Name | DPX-6000MD |
|---|---|
| Manufacturer | Kenwood |
| Released | 1999/06 |
| Device type | auto |
| Recorder | Player |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 2-Din 178 (W) x 100 (H) x 155 (D) mm |
| Weight | 2700 |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | |
| Voltage | 12 |
| Power cable | |
| Price (launch) | |
| ¥69 800 | |
| - | |
| Inputs | CD |
| Outputs | |
| Control |
Dual size MD/CD receiver at an affordable price. 20bit resolution is installed in MD playback, enabling MD playback with high sound quality. The display is equipped with a variety of spectrum analyzer functions, including 3 patterns of silent mode, 9 patterns of standard mode, and 9 patterns of upbeat mode, making the interior of the car fun. In addition, 6 types of DSPs that realistically reproduce the sense of presence and a 4-mode equalizer create the desired sound quality in the car. Equipped with 35W x 4ch high power amplifier.
[CD section]
- Frequency response: 10Hz to 20kHz (±1dB)
- S/N ratio: 93dB (1kHz)
- Dynamic range: 93dB
- Stereo Separation: 85dB
[MD department]
- Frequency response: 20Hz to 20kHz (±1dB)
- S/N ratio: 90dB (1kHz)
- Dynamic range: 90dB
- Stereo Separation: 80dB
[FM section]
- Receiving frequency range: 76.0MHz to 90.0MHz (100kHz steps)
[AM section]
- Receiving frequency range: 522kHz to 1629kHz (9kHz steps) Sensitivity: 28dBμ
[Audio part]
- Maximum output: 35W x 4
- Rated output: 21W x 4 (4Ω, 1kHz, 10%THD)
- Pre-out level: 1500mV (FM/10kΩ)
[Common part]
- Power supply voltage: 14.4V (11 to 16V)
- Maximum current consumption: 10A
- Embedded dimensions: 178 (W) x 100 (H) x 155 (D) mm
- Mass: 2.7kg
Content adapted from: Kenwood Press Release (archived) [*] Kenwood Press Release (archived) (MiniDisc Wiki mirror) [*]
