Fuze MDX-1
| Name | MDX-1 |
|---|---|
| Manufacturer | Fuze |
| Released | |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 260mm/Speaker 255mm |
| Weight | 4700 |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | |
| Voltage | 100 |
| Power cable | |
| Price (launch) | |
| ¥55 000 | |
| - | |
| Inputs | RCA in, CD, Tape deck |
| Outputs | 3.5mm headphone |
| Control |
Fuze MDX-1.
5 editing functions, MD synchronized recording, MD throttle-in method, 32-track program, skip, search, random, repeat functions
◆Product specifications
- RADIO frequency: AM522～1629kHz FM76～108MHz (TV1～3ch)
- Receiving frequency characteristics: CD/MD 20Hz～20kHz
- Power supply: AC100V ( 50/60Hz)
- Practical maximum output: 10W＋10W
- Power consumption: 60W
- Speaker: 3-way (ultra-high-pitched buzzer 2.0cm, tweeter 5.0cm, woofer 10cm)
- Color: Main unit/silver Speaker/blue
- Full size (main unit/speaker x 2): Width 518 x Height 265 x Depth Main unit 260mm/Speaker 255mm
- Weight: Approx. 4.7kg Speaker 2.3kg (per unit)
- Set contents: Main unit (1), speaker (2), AC cord (1), remote controller (1), AM antenna (1) , FM antenna (1), Instruction Manual/Warranty
