Clarion DMZ735LP
| Name | DMZ735LP |
|---|---|
| Manufacturer | Clarion |
| Released | 2003/07 |
| Device type | auto |
| Recorder | |
| MDLP | Yes |
| NetMD | |
| Hi-MD | |
| Radio | Yes |
| Dimensions | 178 (W) x 100 (H) x 185 (D) mm |
| Weight | 3100 |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | |
| Voltage | 12 |
| Power cable | |
| Price (launch) | |
| ¥71 400 | |
| - | |
| Inputs | 3.5mm line in (analog-only), RCA in, CD |
| Outputs | |
| Control |
Clarion DMZ735LP
MD player part Frequency characteristic 20Hz-20kHz (± 2dB)
SN ratio 90dB
Dynamic range 82dB
CD player section Frequency characteristic 5Hz-20kHz (± 1dB)
SN ratio 100dB
Dynamic range 92dB
Audio part Rated output
18W x 4 (20Hz-20kHz, 1%, 4Ω)
Maximum output 50W x 4 (JEITA)
Compatible speaker impedance 4Ω (4Ω to 8Ω)
Lineout output level 1.8V (CD1kHz)
AUX section
- Input sensitivity (at 1.8V output)
- LOW: 1V
- MID: 650mV
- HIGH: 330mV
Content adapted from: Clarion Press Release [*]
