Clarion DMZ355
| Name | DMZ355 |
|---|---|
| Manufacturer | Clarion |
| Released | 2005/05 |
| Device type | auto |
| Recorder | Player |
| MDLP | Yes |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 178 (W) x 100 (H) x 184.5 (D) mm |
| Weight | 2200 |
| ATRAC ver | |
| Battery | |
| Battery notes | |
| Sidecar (depr) | |
| Voltage | 12 |
| Power cable | |
| Price (launch) | |
| ¥39 900 | |
| - | |
| Inputs | CD |
| Outputs | |
| Control |
“728 color variable color” linked with audio key illumination Adopted “728 color variable color” that gives off rich colors. It also works with audio key illumination to create an interior space that suits your taste.
Rotary volume control By adopting a large rotary volume, comfortable and reliable operation has been realized.
DSP From a total of 5 types of basic patterns, STADIUM, HALL, CLUB, CHURCH, and L-ROOM, you can select the sound field and presence that suits your music genre and taste.
Z Enhancer Plus In addition to being able to select from three equalizing patterns (B-BOOST / IMPACT / EXCITE) according to the music genre, it is equipped with a 2BAND parametric equalizer function that allows fine adjustment of sound quality by freely setting the gain-Q of each pattern. ..
iPod connection possible * Connection is possible with the EA1251AA (CeNET iPod interface box) scheduled to be released in October. Rating
MD player part
- Frequency range: 20Hz-20kHz (± 2dB)
- SN ratio: 90dB
- Dynamic range: 85dB
CD player section
- Frequency range: 5Hz-20kHz (± 1dB)
- SN ratio: 100dB
- Dynamic range: 95dB
AUX section
- Input sensitivity: (at 2V output)
- HIGH: 650mV
- MID: 1.3V
- LOW: 2.0V
Audio part
- Rated output: 17W x 4 (20Hz-20kHz, 1%, 4Ω)
- Maximum output: 50W x 4 (EIAJ)
- Compatible impedance: 4Ω (4Ω to 8Ω)
- Lineout output level: 1.8V (CD1kHz)
- Current consumption: 3.0A (at 1W)
- Fuse rating: 15A / 3A
Content adapted from: av.watch [*] Clarion DMZ355 Press Release [*]
