Aiwa XR-MD100

Main features

• Entire system is a compact 49.1cm wide
• The center unit, integrating the MD deck, CD player, single cassette deck, and tuner, measures just 17.5cm wide. With the speakers, the entire system is only 49.1cm wide.
• High power 60W amplifier
• Sampling rate converter for digital recording from BS/CS digital broadcasts and DAT, to MD. The sampling rate converter automatically converts 32kHz/48kHz sampling frequencies to 44.1kHz. This allows high-quality digital MD recording from external equipment such as BS/CS digital tuners and DAT, in addition to CDs.
• BBE sound processing system ensures precise mid- and high- range balance.
• Virtual stereo QSURROUND offers natural stereophonic surround effects.
• Energy-saving design
• The XR-MD100 consumes just 1.4W when plugged in with power off in energy-saving standby mode.
• Multi-function MD deck ensures precise recording and editing
• 1.Direct recording (all programs/one program) from CD to MD
• 2.Simultaneous recording from CD to MD and cassette tape
• 3.Full editing functions (divide, combine, move, erase)
• 4.Monaural extended recording mode allows recording up to 160 minutes on an 80-minute MD.
• 5.Double-speed playback function ensures faster, more efficient program selection.
• 6.Multi jog dial allows simple inputting of up to 50 alpha numeric or kana, characters.
• 7.MD 30-track program playback/random playback
• 8.Display shows remaining MD recording time
• 9.Auto mark, time mark, and manual mark functions for MD recording
• * Two-way wooden cabinet speakers reproduce natural, high-quality sound.
• * Music genre position switch (rock, pop, jazz)
• * Dolby B NR
• * Easy-to-operate multi jog dial allows various settings.
• The XR-MD100's multi jog dial is convenient for adjusting sound characteristics such as T-Bass and BBE as well as Dolby NR settings and tuner and CD operation.
• FM stereo (wide)/AM stereo 2-band synthesized tuner (with random memory presets of up to 32 stations).
• Recording/playback auto reverse cassette deck
• CD 30-track program/random/repeat playback
• Edit recording (AI/Program) from CD to cassette
• Direct play function allows one-touch activation of MD, CD, cassette tape playback, or tuner, even if the main power switch is off.
• Full remote control
• Music sensor fast-forwards or rewinds the tape to the beginning of the current track, the preceding track, or the next track.
• Silver body color

FM: 87.5MHz - 108MHz

Optical Pickup: KMS-260
ATRAC IC: CXD2652AR

Content adapted from: Aiwa Press Release [*] Aiwa Press Release (MiniDisc Wiki mirror) [*]

Aiwa XR-MD100 Operating Instructions Manual ENG / ES / FR

Aiwa XR-MD100 Service Manual
